Image Sensor: | 1/2.8″Sony335 5MP CMOS |
Signal System: | PAL/NTSC |
Min. Illumination: | Color: 0.05lux @(F1.2, AGC ON), 0 lux with IR |
Shutter Time: | 1/25 s to 1/100,000 s |
Lens: | 5-60mm Manual Lens |
Day&Night: | IR cut filter with auto switch |
Image Enhancement: | BLC/3D DNR/D-WDR |
Motion Detection | Support |
Privacy Protection | Support(4 Self-customized Areas) |
Water-Proof: | IP66 |
Illumination for Infrared Switching: | 0.5~3Lux |
Infrared Wavelength: | 850nm |
Mimimum Illumination: | 0 Lux(IR ON) |
IR Range: | 4pcs White LEDs//35m IR + 2pcs IR LEDs //30m |
Compression Standard |
Video Compression: | H.265/H.264/MJPEG |
Video Bit Rate: | 32Kbps~12Mbps(CBR/VBR Selectable) |
Audio Compression: | G711U/G711A |
Dual Streams: | Yes |
Triple Streams: | Yes |
Image |
Max. Image Resolution: | 2592×1944(5MP)@30fps |
Frame Rate: | 50/60Hz:2592*1944@25fps,(2560*1920/2304*1296/2048*1536/1080P/960P/720P/D1)@25fps |
Sub Stream: | 50Hz/60Hz: (720*480/VGA/640*360/480*360/CIF)@25fps |
Third Stream(Mobile Stream): | 50/60Hz: (1080P/720P/CIF)@5fps |
Image Settings: | 3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness adjustable via client software, web browser or Smartphone App |
Day/Night Switch: | Auto(Passive Mode)/Day/Night/Auto(Active Mode)/Time |
Network |
Network Protocols: | HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,RTMP, DDNS, IP Search(Support Danale IP camera, DVR, NVS and etc.) |
General Function: | Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark |
System Compatibility: | ONVIF(17.06 ) profile S/Danale(P2P) |
On-line Viewing | Max. Support 6 Users Simultaneously |
Interface |
Communication Interface: | 1 RJ45 10M / 100M Ethernet Interface |
RCA Audio Interface: | RCA Audio input/output Interface (Optional) |
DC Power Plug: | DC Power Female Interface |
General |
Operating Conditions: | -10 °C ~ 60 °C |
Humidity 95% or less (non-condensing) |
Power Supply: | 12 V DC ± 10%/PoE(Optional) |
Power Consumption: | 12 VDC ± 10%, Max Power Comsumption Less than 10W (When the infrared lamps turn on) |
Weight: | 1.10KG |
