SKU: UNVR Category:
  • UNVR – UniFi Protect Network Video Recorder
  • UNVR support a video recorder (4) 2.5/3.5″ HDD bays that can support up to 30 days of storage for (15)
  • UNVR support a video recorder 4K cameras or (50) Full HD cameras UniFi Protect
  • UNVR support (4) 3.5″ HDD / SSD support
  • (1) 10G SFP+ uplink and (1) GbE RJ45 port
  • Data protection with RAID storage technology
  • DC power backup-ready
Product is rated as #1 in category NVR

UniFi Protect Network Video Recorder

UniFi Protect Network Video Recorder (UNVR)

The UniFi UNVR is an enterprise network video recorder tha t integ r a tes a n NVR, the UniFi Protect software, and a 4-drive bay. The UNVR unifies enterpr ise-class data protection a ndsca lable storage with simple plug and play integration using the intuitive UniFi Protect software.

From a desktop computer or mobile device, you can a ccess your surveilla nce recording s from virtua lly a nywher e using the intuitive graphica l user inter face. The mobile app is available for iOS and Android-ba sed devices.

The drive bay sareea sily a ccessed from the front panel, so hard driv e mounting and maintena nceare simple. Using four 8 TB drives in a RAID 5 configuration, the UNVR can provide up to 30 days of 4k video storage for 15 cameras or Full HD video storage for 50 cameras by UNVR.

UNVR Technical Specifications

Mechanical
Dimensions442.4 x 325 x 43.7 mm (17.4 x 12.8 x 1.7″)
WeightWithout mounting brackets: 5.1 kg (11.3 lb)
With mounting brackets: 5.2 kg (11.5 lb)
Enclosure materialSGCC steel
Mount materialSGCC steel
Hardware
Management interfaceEthernet In-Band
Networking interface(1) GbE RJ45 port
(1) 1/10 GbE SFP+ port
Power method(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 10.43A
Power supplyAC/DC, internal, 120W
Supported voltage range100—240V AC
Max. power consumption100W
Max. power budget for Drives75W
ESD/EMP protectionAir: ± 12kV, contact: ± 8kV
Operating temperature-5 to 40° C (23 to 104° F)
Operating humidity5 to 95% noncondensing
CertificationsFCC, CE, IC
LEDs
System(1) Power: blue/white
Flashing white: bootup in progress
Flashing blue: firmware upgrading
Steady white: factory defaults, awaiting adoption
Steady blue: device is adopted
EthernetGreen: 1 Gbps
Amber: 10/100 Mbps
SFP+White: 10 Gbps
Green: 1 Gbps
HDDWhite: disk detected
Amber: disk error
RPSBlue: ready
