UNVR
- UNVR – UniFi Protect Network Video Recorder
- UNVR support a video recorder (4) 2.5/3.5″ HDD bays that can support up to 30 days of storage for (15)
- UNVR support a video recorder 4K cameras or (50) Full HD cameras UniFi Protect
- UNVR support (4) 3.5″ HDD / SSD support
- (1) 10G SFP+ uplink and (1) GbE RJ45 port
- Data protection with RAID storage technology
- DC power backup-ready
Zalo:
- Kinh Doanh OnlineWhatsApp:
- Tư Vấn Giải PhápFacebook:
- Hỗ Trợ Đơn HàngSales Engineer:
- 0989 544 978UniFi Protect Network Video Recorder
The UniFi UNVR is an enterprise network video recorder tha t integ r a tes a n NVR, the UniFi Protect software, and a 4-drive bay. The UNVR unifies enterpr ise-class data protection a ndsca lable storage with simple plug and play integration using the intuitive UniFi Protect software.
From a desktop computer or mobile device, you can a ccess your surveilla nce recording s from virtua lly a nywher e using the intuitive graphica l user inter face. The mobile app is available for iOS and Android-ba sed devices.
The drive bay sareea sily a ccessed from the front panel, so hard driv e mounting and maintena nceare simple. Using four 8 TB drives in a RAID 5 configuration, the UNVR can provide up to 30 days of 4k video storage for 15 cameras or Full HD video storage for 50 cameras by UNVR.
UNVR Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 325 x 43.7 mm (17.4 x 12.8 x 1.7″) |
| Weight | Without mounting brackets: 5.1 kg (11.3 lb) With mounting brackets: 5.2 kg (11.5 lb) |
| Enclosure material | SGCC steel |
| Mount material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (1) GbE RJ45 port (1) 1/10 GbE SFP+ port |
| Power method | (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 10.43A |
| Power supply | AC/DC, internal, 120W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 100W |
| Max. power budget for Drives | 75W |
| ESD/EMP protection | Air: ± 12kV, contact: ± 8kV |
| Operating temperature | -5 to 40° C (23 to 104° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | FCC, CE, IC |
| LEDs | |
| System | (1) Power: blue/white Flashing white: bootup in progress Flashing blue: firmware upgrading Steady white: factory defaults, awaiting adoption Steady blue: device is adopted |
| Ethernet | Green: 1 Gbps Amber: 10/100 Mbps |
| SFP+ | White: 10 Gbps Green: 1 Gbps |
| HDD | White: disk detected Amber: disk error |
| RPS | Blue: ready |
