IAP-134

The AP-134 features two 3×3 MIMO dual-band 2.4-GHz/5-GHz
radios with external antenna interfaces, while the AP-135 features
the same radios with internal antennas. Both are built to provide
years of trouble-free operation and are backed by a limited
lifetime warranty.
MACSec authentication and encryption on Ethernet ports enable
secure AP deployment by interoperating with the MACSec
capability on Aruba Mobility Access Switches and other wiring
closet devices.
The AP-134 and AP-135 feature dual 10/100/1000BASE-T
Ethernet interfaces and operate from standard 802.3af and
802.3at power-over-Ethernet (PoE) sources. The secondary
Ethernet interface (active only when supplying 802.3at PoE or DC
power to the access point) enables secure authorized backhaul for
wired network-attached devices.
Working with Aruba’s line of centralized Mobility Controllers, the
AP-134 and AP-135 deliver secure, high-speed network services
that move users to a “wireless where possible, wired where
necessary” network access model. The network can then be
rightsized by eliminating unused Ethernet switch ports and thereby
reducing operating costs.
The key to ensuring wire-like performance and reliability is Aruba’s
unique Adaptive Radio Management and spectrum analysis
capabilities, which manage the 2.4-GHz and 5-GHz radio bands to
deliver maximum client performance while mitigating any
RF interference AP-134 and AP-135 Access Points

WIRELESS RADIO SPECIFICATIONS
• AP type: Dual-radio, dual-band 802.11n indoor
• Supported Frequency Bands (country-specific restrictions apply):
– 2.400 – 2.4835 GHz
– 5.150 – 5.250 GHz
– 5.250 – 5.350 GHz
– 5.470 – 5.725 GHz
– 5.725 – 5.875 GHz
• Available Channels:
• Controller-managed, dependent upon configured
regulatory domain
• Platform supports Dynamic Frequency Selection (DFS) to allow
optimal usage of available RF spectrum
• Supported Radio Technologies:
– 802.11b: Direct-sequence spread-spectrum (DSSS)
– 802.11a/g/n: Orthogonal frequency division multiplexing
(OFDM)
– 802.11n: 3×3 MIMO with up to three spatial streams
• Supported Modulation Types:
– 802.11b: BPSK, QPSK, CCK
– 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
• Transmit Power: Configurable in increments of 0.5 dBm
• Maximum Transmit Power (aggregated for three active transmit
chains):
– 2.4 GHz: 23 dBm (limited by local regulatory requirements)
– 5 GHz: 23 dBm (limited by local regulatory requirements)
• Maximum Ratio Combining (MRC) for improved receiver
performance
• Short guard interval for 20-MHz and 40-MHz channels
• Space Time Blocking Code (STBC) for increased range and
improved reception
• Low Density Parity Check (LDPC) for high efficiency error
correction and increased throughput
• Transmit Beam-forming (TxBF) ready platform for increased
reliability in signal delivery
• Cyclic Delay Diversity for improved downlink RF performance
• Association Rates (Mbps):
– 802.11b: 1, 2, 5.5, 11
– 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
– 802.11n: MCS0 – MCS23 (6.5 Mbps to 450 Mbps)
• 802.11n High-Throughput (HT) Support: HT 20/40
• 802.11n Packet Aggregation: A-MPDU, A-MSDU

POWER
• 48 V DC 802.3af PoE or 802.3at PoE+
• 12 V DC external AC supplied power (adapter sold separately)
• Maximum power consumption: 15 watts
INTERFACES
• Network:
– 2×10/100/1000BASE-T Ethernet (RJ-45), auto-sensing link
speed and MDI/MDX
– Supports MACSec encryption, 802.3az (EEE)
– 48 V DC 802.3af PoE or 802.3at PoE+ interoperable with
intellisource power sourcing equipment (both ports)
• Antenna (model AP-134 only):
– 3 x RP-SMA antenna interfaces (supports up to 3×3 MIMO)
• Other:
– 1 x RJ-45 console interface
AP-134 and AP-135 Access Points
The multifunction AP-134 and AP-135 can be configured through
the Mobility Controller to provide WLAN access with part-time air
monitoring for wireless IPS and spectrum analysis. They can be
configured as dedicated air monitors within the campus WLAN
or can be remotely located. They can enable wireless mesh
networking for high performance network backhaul where wired
cabling is not available.
