IAP-115

ADVANCED CELLULAR COEXISTENCE (ACC)
The 110 series Advanced Cellular Coexistence (ACC) feature
enables Aruba WLANs to perform at peak efficiency
by minimizing interference from 3G/4G LTE networks,
distributed antenna systems and commercial small-cell/
femtocell equipment.

WI-FI CLIENT OPTIMIZATION
To eliminate sticky client behavior while users roam, the
110 series features patented ClientMatch technology, which
continuously gathers session performance metrics from
mobile devices.
If a mobile device moves out of range of an AP or if
RF interference impedes performance, ClientMatch
automatically steers the device to a better AP.
For large installations across multiple sites, the Aruba
Activate service significantly reduces deployment time by
automating device provisioning, firmware upgrades, and
inventory management. With Aruba Activate, Instant APs are
factory-shipped to any site and configure themselves when
powered up.
If WLAN and network requirements change, a built-in
migration path allows 110 series Instant APs to become part
of a WLAN that is centrally managed by a Mobility Controller

OPERATING MODES
• 802.11a/b/g/n controllerless Aruba Instant AP
• 802.11a/b/g/n Mobility Controller-managed AP
• Remote AP (RAP)
• Spectrum analysis identifies sources of RF interference
• Air monitor provides wireless intrusion protection
• Hybrid AP serves Wi-Fi clients and provides wireless
intrusion protection and spectrum analysis
• Secure enterprise mesh

SECURITY
• With an OpenDNS service subscription, Aruba Instant
RAPs deliver integrated web filtering, malware and botnet
protection to every device connected to the WLAN
• Integrated Trusted Platform Module (TPM) for secure
storage of credentials and keys
• SecureJack-capable for secure tunneling of wired
Ethernet traffic

WIRELESS RADIO SPECIFICATIONS
• AP type: Indoor, dual radio, 5-GHz and 2.4-GHz
802.11n 3×3:3
• Software-configurable dual radio supports 5-GHz (Radio 0)
and 2.4-GHz (Radio 1)
• 3×3 MIMO with three spatial streams and up to 450 Mbps
wireless data rate
• Support for up to 255 associated client devices per radio,
and up to 16 BSSIDs per radio
• Supported frequency bands (country-specific
restrictions apply):
– 2.4000 to 2.4835 GHz
– 5.150 to 5.250 GHz
– 5.250 to 5.350 GHz
– 5.470 to 5.725 GHz
– 5.725 to 5.850 GHz
• Available channels: Dependent on configured
regulatory domain

ANTENNAS
• AP-114: Three RP-SMA connectors for external dualband antennas. Internal loss between radio interface and
external antenna connectors (due to diplexing circuitry):
1.5 dB in 2.4-GHz and 2.5 dB in 5-GHz.
• AP-115: Six integrated downtilt omni-directional antennas
for 3×3 MIMO with maximum antenna gain of 4.5 dBi
in 2.4-GHz and 5.5 dBi in 5-GHz. Built-in antennas are
optimized for horizontal ceiling mounted orientation
of AP-115. The downtilt angle for maximum gain is
approximately 30 degrees.

OTHER INTERFACES
• 10/100/1000BASE-T Ethernet network interface (RJ-45)
– Auto-sensing link speed and MDI/MDX
– 802.3az Energy Efficient Ethernet (EEE)
– PoE-PD: 48 Vdc 802.3af PoE or 802.3at PoE+
• DC power interface, accepts 1.7/4.0-mm center-positive
circular plug with 9.5-mm length
• USB 2.0 host interface (Type A connector)
• Serial console interface (RJ-45)
• Visual indicators (LEDs):
– Power/system status
– Ethernet link status (ENET)
– Radio status (2x; RAD0, RAD1)
• Kensington security slot
• Reset button

MOUNTING
• Included with AP:
– Mounting brackets (2) for attaching to 9/16-inch or
15/16-inch T-bar drop-tile ceiling
• Optional mounting kits:
– AP-220-MNT-C2: Aruba AP mount kit contains two
ceiling-grid rail adapters for Interlude and Silhouette
style rails
– AP-220-MNT-W1: Aruba AP mount kit contains one
flat-surface wall/ceiling mount bracket
– AP-220-MNT-W2: Aruba AP mount kit contains one
flat-surface wall/ceiling secure mount cradle

MECHANICAL
• Dimensions/weight (unit, excluding mount accessories):
– 180 mm (W) x 180 mm (D) x 45 mm (H)
– 7.09” (W) x 7.09” (D) x 1.77” (H)
– 650 g (1.43 lbs)
