Cambium ePMP Force 300 Series
Service providers face ever-increasing demand for capacity in a limited amount of spectrum. The ePMP™ Force 300 series of subscriber modules (SM) meets this demand, offering high performance and low latency across both point-to-multipoint (PMP) and point-to-point (PTP) deployments.
Force 300 SM series offers a wide range of antenna options with the following differentiating features:
- Up to 600 Mbps capacity and latencies as low as 2 ms when using ePTP technology
- Proven air interface on top of 802.11ac Wave 2 technology
- Interoperability with the ePMP 3000, which uses MU-MIMO to achieve 1.2 Gbps per sector by transmitting to 2 Force 300 SMs simultaneously
- Interoperability with ePMP 3000L and ePMP 3000 MicroPOP and backward compatibility with the ePMP 2000 and ePMP 1000
- Integrated always-on spectrum analyzer for assessing the noise floor across a wide swath of 5 GHz spectrum
- Multiple levels of QoS (Quality of Service) for voice, video, and data applications supporting a wide variety of service packages for both residential and enterprise users
- Security features that meet the requirements of enterprise, industrial, government, and service provider users
- Management by Cambium Networks cnMaestro™ Network Management System for easy provisioning, monitoring, and upgrades
- Network planning with LINKPlanner and cnHeat
- Cambium Networks’ 3-year hardware warranty and support
- Power over Ethernet (PoE) injector and pole mount hardware included
C050910M001C Datasheet
| Channel Spacing | Configurable on 5 MHz increments |
| Frequency Range | 4910 – 5980 MHz (exact frequencies as allowed by local regulations) |
| Channel Width | 20 | 40 | 80 MHz |
| Interface | |
| MAC (Media Access Control) Layer | Cambium |
| Proprietary Physical Layer | 2×2 MIMO/OFDM |
| Ethernet Interfaced | 10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts |
| Protocols Used | IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH |
| Network Management | IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro™ |
| VLAN | 802.lQ with 802.1p priority |
| Performance | |
| ARQ | ✓ |
| Nominal Receive Sensitivity (w/FEC) @20MHz Channel | MCS0 = -87 dBm to MCS8 (256 QAM-3/4) = -63 dBm (per chain) |
| Nominal Receive Sensitivity (w/FEC) @40MHz Channel | MCS0 = -85 dBm to MCS9 (256QAM-5/6) = -59 dBm (per chain) |
| Nominal Receive Sensitivity (w/FEC) @80 MHz Channel | MCS0 = -82 dBm to MCS9 (256QAM-5/6) = -56 dBm (per chain) |
| Modulation Levels (Adaptive) | MCS0(BPSK)to MCS9 (256QAM5/6) |
| Transmit Power Range | 0 to +27 dBm (combined, to regional EIRP limit) (1 dB interval) |
| Physical | |
| Surge Suppression | 1 Joule Integrated (C000000L065A – 30V Gigabit surge suppressor is recommended for optimum protection) |
| Environmental | IP55 |
| Weight | 2.4 kg |
| Wind Survival | 180 km/hour (112 mi/hour) |
| Dimensions (Dia x Depth) | 7 cm x 31 cm |
| Pole Diameter Range | 6.4 cm – 7.6 cm |
