X7-35X
- X7-35X Wi-Fi 7 Indoor Access Point
- 802.11be Tri-Radio 2+2+2 Access Point with BLE/Zigbee
- Tri-radio/tri-band Wi-Fi 7
- 6GHz radio disabled
- 9.2 Gbps aggregate data rate
- 2.5 GbE uplink port
- LPI (low power indoor) mode
- Managed by cnMaestro™
Zalo:
- Kinh Doanh OnlineWhatsApp:
- Tư Vấn Giải PhápFacebook:
- Hỗ Trợ Đơn HàngSales Engineer:
- 0989 544 978Cambium X7-35X Wi-Fi 7 Indoor Access Point
Cloud and On-Premises Management
X7-35X operates using Cambium’s cnMaestro Network Management, accessible on both cloud and on-premises platforms. Aligned with Cambium’s ONE Network, cnMaestro facilitates the management of all devices through a user-friendly interface, streamlining control from backhaul to edge devices. This enables you to start managing your network right away, reducing training and troubleshooting time.
Fast Installation
The X7-35X Wi-Fi 7 AP streamlines installation, saving you time and money. Its multi-functional mounting system easily installs the access point over multiple telecom and electrical junction boxes, on a suspended drop ceiling system, or to any flat surface. The recessed Ethernet port and trim mounting bracket enables an aesthetically pleasing installation and final finish. Plus, the new Wi-Fi 7 junction box bracket is backwards compatible with the XV3-8 and XE3-4.
X7-35X-0A00-RW Datasheet
| Radios | • 2.4 GHz 2×2:2 with 802.11 b/g/n/ax/be • 5 GHz 2×2:2 with 802.11 a/n/ac/ax/be • 6 GHz 2×2:2 with 802.11 ax/be |
| BLE and Zigbee | • Built-in BLE or 802.15.4 radio • Max Transmit power 20 dBm with the integrated 5 dBi omnidirectional antenna gain |
| Supported data rates | • 802.11be: 7.3 to 5765 Mbps • 802.11ax: 7.3 to 2402 Mbps • 802.11ac: 6.5 to 1733 Mbps • 802.11n: 6.5 to 300 Mbps • 802.11a/g and a: 6 to 54 Mbps • 802.11b: 1 to 11 Mbps |
| Max PHY Rate | • 2.4 GHz: 574 Mbps • 5 GHz: 2882 Mbps • 6 GHz: 5765 Mbps |
| Antenna | • Omnidirectional internal antennas (Peak gain) 2.4 GHz: 5 dBi 5 GHz: 6 dBi 6 GHz: 6 dBi • BLE and Zigbee: 5 dBi |
| Maximum Radio Tx Power (combined Tx power across all Tx chains) | • 2.4 GHz: 24 dBm, max EIRP: 29 dBm • 5 GHz: 25 dBm, max EIRP: 31 dBm • 6 GHz: 25 dBm, max EIRP: 31 dBm |
| MIMO Support | • 2×2 (2.4 GHz, 5 GHz, and 6 GHz) SU-MIMO • 2×2 (2.4 GHz, 5 GHz, and 6 GHz) MU-MIMO both in UL and DL direction |
| USB Interface | • 1 USB 2.0 type A port, max 1.5 W power supply |
| Ethernet Interface | • 1 x 100 Mbps/ 1 Gbps / 2.5 Gbps PoE port |
| Power | • Max power consumption 25.5W (802.3at) • Typical power consumption with BLE / 802.15.4 radio enabled: 10.6W • LLDP power negotiation support |
| Dimensions | • 209.6 mm x 209.6 mm x 45 mm |
| Weight | • Weight: 935 gm |
| Mount Options | • Drop ceiling T-bar, ceiling tile, 4″ square electrical box, 4″ round box, NA single gang box, EU single gang box, wall mount |
| Physical Security | • Kensington lock slot |
| LEDs | • Multicolor status LED • Blue: Managed from cnMaestro • Green: Up and running, not managed from cnMaestro • Amber: Booting |
| Ambient Operation Temperature | • 0ºC – + 50ºC |
| Storage Temperature | • -20ºC – + 70ºC |
| Operating Humidity | • 95% RH non-condensing |
| Reliability | • MTBF 8,29,316 hours at +25ºC operating temperature |
| Device Management | • cnMaestro Cloud / On-Premises management (version 5.1 and above) • Standalone operation mode • Web access with HTTPs / HTTP protocol • CLI access with SSH / telnet protocols |
