RG-AP850-I (V2)
- RG-AP850-I(V2) Wi-Fi 6 Tri-Radio 6817 Mbps High-density Indoor AP
- Indoor scenarios in higher education, government, general education, finance, and business sectors
- Upgraded to Wi-Fi 6, a combined data rate of up to 6817 Mbps
- Support PoE power supply, easier deployment
- Flexible switching between fat and fit modes, flexible networking
- Unified cloud management, intelligent tuning, and easier O&M
Mr Minh: - Kinh Doanh
Mr Luân: - Kinh Doanh
WhatsApp: - Tư Vấn Giải Pháp
Facebook: - Hỗ Trợ Đơn Hàng
Sales Engineer: - 0989 544 978
RG-AP850-I (V2) is our next-generation flagship ultra-highperformance Wi-Fi 6 enterprise AP designed for challenging high density indoor scenarios. With the built-in IoT module, enterprise customers can be ready for future IoT expansion to boost the operational efficiency and customer experience. The Ruijie RG-AP850-I(V2) supports concurrent dual-band tri-radio, up to 10 total spatial streams and a maximum of 6.817Gbps wireless throughput.
Taking the advantage of Wi-Fi 6 OFDMA Modulation, MUMIMO, and BSS Color Spatial Reuse, the RG-AP850-I (V2) guarantees minimal signal interference and a maximum of 1536 client connections. Additionally, RG-AP850-I (V2) provide three Ethernet ports with totally 3G wired access capacity, including two Gigabit Uplink port, and one LAN port for external IoT sensor connection with PoE out (passive) feature. All Ruijie enterprise Aps support hybrid management mode. Either deployed as standalone AP (Fat mode) or managed AP (Fit mode), the AP will detect the operation mode automatically without extra effort on firmware upgrade. For additional security and operation, we recommend the enterprise customers to choose either one of the below wireless controller options depending on the functionality and capacity:
Hybrid Cloud: RG-WS6000 Series Wireless Controller (on-premises) Plus Cloud Management (Optional) – targeted for enterprise office and campus with single or multiple sites and high-density AP deployment. The controller appliances are installed at the customer’s site with fully integrated wireless management and authentication feature, supporting up to 5000 APs per cluster. Optionally, the cloud management platform allows for value-added features like centralized device configuration and monitoring, AI radio (RF) optimization, reporting, etc. Product Highlights Product Overview.
Private Cloud: RG-MACC Software Controller – targeted for ISP/MSP, government, or multi-national corporation (MNC) with diverse customer sites and demand on integration of their billing, portal and security systems. The RG-MACC supports unified device management, not only for wireless access points, but also switches and gateway devices.
Product Highlights
- Max 6.817Gbps (Total 10 Spatial Streams) with Concurrent Dual-Band Design.
- Max 3G wired access capacity (with dual 10G port design).
- Max 1536 Client connections.
- OFDMA, MU-MIMO and BSS Technology for minimal wireless signal interference.
- IoT Ready: Integrated with BLE module and one IoT extension port with PoE Out (passive).
- AI Wireless Optimization: one – click optimization powered by Ruijie Cloud technology.
- Hybrid Management: support standalone AP to over thousands of APs with deployment options of appliances, private cloud or public cloud service.
- Mobility Management: Free mobile app available for RG-MACC-Base private cloud or Ruijie Public Cloud customers.
Dimensions and Weight | RG-AP850-I (V2) |
Physical dimensions (W x D x H) | 220 mm x 220 mm x 48.85 mm (8.66 in. x 8.66 in. x 1.92 in.) |
Weight | AP: 1.3 kg (2.87 lbs) Mounting bracket: 0.2 kg (0.44 lbs) |
Installation | Ceiling-mounting or wall-mounting |
Lock option | Securing latch and Kensington lock |
Radio Specifications | RG-AP850-I (V2) |
Radio design | Tri-radio design, ten spatial streams Radio1: 2.4 GHz, four spatial streams: 4×4 MU-MIMO Radio2: 5 GHz, two spatial streams: 2×2 MIMO Radio3: 5 GHz, four spatial streams: 4×4 MU-MIMO |
Operating frequencies | Radio1: 802.11b/g/n/ax: 2.400 GHz to 2.483 GHz Radio2: 802.11a/n/ac: 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz Radio3: 802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz Note: The operating radio is country-specific. |
Data rate | Radio 1: 2.4 GHz, 1.15 Gbps Radio 2: 5 GHz, 867 Mbps Radio 3: 5 GHz, 4.8 Gbps Combined: 2.4 GHz + 5 GHz + 5 GHz, 6.817 Gbps |
Antenna type | Built-in smart antennas |
Antenna gain | 2.4GHz: 3 dBi 5GHz: 3 dBi |
Max. transmit power | 20 dBm Note: The transmit power varies based on the regulations in different countries and regions. |
Power adjustment | 1 dBm |
Modulation | OFDM: BPSK @ 6/9 Mbps, QPSK @ 12/18 Mbps, 16-QAM @ 24 Mbps, and 64-QAM @ 48/54 Mbps DSSS: DBPSK @ 1 Mbps, DQPSK @ 2Mbps, and CCK @ 5.5/11 Mbps MIMO-OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, and 1024-QAM OFDMA |
Receive sensitivity | 802.11b: –96 dBm (1 Mbps), –93 dBm (5 Mbps), and –89 dBm (11 Mbps) 802.11a/g: –91 dBm (6 Mbps), –85 dBm (24 Mbps), –80 dBm (36 Mbps), and –74 dBm (54 Mbps) 802.11n: –90 dBm @ MCS0, –70 dBm @ MCS7, –89 dBm @ MCS8, –68 dBm @ MCS15 802.11ac: HT20: –88 dBm (MCS0) and –63 dBm (MCS9) 802.11ac: HT40: –85 dBm (MCS0) and –60 dBm (MCS9) 802.11ac: HT80: –82 dBm (MCS0) and –57 dBm (MCS9) 802.11ac: HT160: –80 dBm (MCS0) and –55 dBm (MCS9) 802.11ax: HE80: –82 dBm (MCS0), –57 dBm (MCS9), and –52 dBm (MCS11) 802.11ax: HE160: –80 dBm (MCS0), –49 dBm (MCS11) |
Port Specifications | RG-AP850-I (V2) |
Bluetooth | Bluetooth 5.0 |
USB port | USB 2.0 |
Fixed service port | Uplink: Two 10/100/1000Base-T Ethernet ports with auto-negotiation, supporting link aggregation. The first port can by powered by PDs. Downlink: One 10/100/1000Base-T Ethernet port with auto-negotiation, supporting power feeding (12 V/2 W) to external devices by PSE, connected to external devices by Ruijie IoT modules |
Fixed management port | One RJ45 console port |
Status LED | One system status LED |
Button | One Reset button |
Power Supply and Consumption | RG-AP850-I (V2) |
Input power supply | (1) 48 V DC/0.6 A power supply (2) PoE/PoE+ power supply, IEEE 802.3af/at-compliant Note: When the AP is powered by IEEE 802.3af-compliant PoE power supply, only Radio1 works, and PSE power supply to external devices and USB functions are disabled). |
External power supply | Supported by PSE (12 V/2 W) |
Max. power consumption | 25.5 W |
Environment and Reliability | RG-AP850-I (V2) |
Temperature | Operating temperature: –10°C to +50°C (14°F to 122°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) Note: At an altitude between 3000 m (9842.52 ft) and 5000 m (16404.2 ft), every time the altitude increases by 220 m (721.79 ft), the maximum temperature decreases by 1°C (1.8°F). |
Humidity | Operating humidity: 5% to 95% RH (non-condensing) Storage humidity: 5% to 95% RH (non-condensing) |
Safety standard | GB 4943.1, IEC 60950-1, IEC 60825-1 |
EMC standard | EN 300386, GB/T 19286, GB/T 17618 |
WLAN Function | RG-AP850-I (V2) |
Maximum number of allowed STAs | 1536 |
Virtual AP service | A maximum of 48 virtual AP services can be provided for the whole machine, and a maximum of 16 ones can be provided for a single RF. |
SSID hiding | Supported |
Each SSID can be configured with an independent authentication mode, encryption mechanism, and VLAN attributes. | Supported |
Remote Intelligent Perceptive Technology (RIPT) | Supported |
Terminal intelligent identification technology | Supported |
Intelligent load balancing based on the number of terminals or traffic | Supported |
STA limit | SSID-based STA limit is supported. Radio-based STA limit is supported. |
Bandwidth limit | STA/SSID/AP-based speed limit is supported. |
Security Function | RG-AP850-I (V2) |
Registration modes such as PSK and Web | Supported |
Data encryption | WPA (TKIP), WPA-PSK, WPA2 (AES), WPA3, and WEP (64/128 bits) are supported. |
WeChat registration | Supported |
QR code visitor registration | Supported |
SMS registration | Supported |
Non-perception registration | Supported |
Data frame filtering | The whitelist, static blacklist, and dynamic whitelist are supported. |
User quarantine | Supported |
Rogue AP detection and countermeasures | Supported |
Dynamic ACL delivery | Supported |
RADIUS protocol | Supported |
CPU Protection Policy (CPP) | Supported |
Network Foundation Protection Policy (NFPP) | Supported |
Routing and Switching Function | RG-AP850-I (V2) |
IPv4 address | The static IP address or DHCP can be obtained. |
Multicast | Multicast conversion to unicast is supported. |
PPPoE | The PPPoE client is supported. |
VPN | The IPsec VPN is supported. |
NAT | Supported (including FTP ALG/DNS ALG) |
Management and Maintenance | RG-AP850-I (V2) |
Network management | Networks can be managed using Telnet and TFTP. Web management is supported. |
Wireless positioning | RBIS is supported. |
Wireless marketing | WMC/MCP is supported. |
Fault detection and alarming | Supported |
Information statistics collection and logs | Supported |
Fat/Fit mode switching | The Fit mode can be switched to the Fat mode by using the AC series wireless controller. The Fat mode can be switched to the Fit mode by using the local control port and Telnet. |
Product Model | Product Description |
RG-AP850-I (V2) | It is a Wi-Fi 6 tri-radio enhanced indoor wireless AP designed for challenging high density indoor scenarios. The whole machine has 10 spatial streams and a maximum access rate of 6.817 Gbps, and supports working under 802.11a/b/g/n/ac and 802.11ax, Fat/Fit mode switching, and 802.3at power feeding and local power feeding. |
