Encoder HD 8X NetUP
- NetUP HDMI Encoder 8x is a professional HDMI H.264 encoder. It is equipped with 8 HDMI inputs and IP output, and also 1 ASI input for re-mux.
- The encoder supports MPEG-4 AVC/H.264 high profile & main profile. It is perfect for encoding signal from DVB receivers, DVD & Blu-ray players.
Ms Nhan:
- Kinh Doanh
Mr Minh: - Kinh Doanh
Mr Luân: - Kinh Doanh
WhatsApp: - Tư Vấn Giải Pháp
Facebook: - Hỗ Trợ Đơn Hàng
Sales Engineer: - 0989 544 978
Hotline: 0933 719 613
- Kinh Doanh
Mr Minh:
- Kinh Doanh
Mr Luân:
- Kinh DoanhWhatsApp:
- Tư Vấn Giải PhápFacebook:
- Hỗ Trợ Đơn HàngSales Engineer:
- 0989 544 978×
Encoder HD 8X NetUP Outline
NetUP Streamer HD v.3 is a professional HD/SD audio & video encoding device. It has 8/16/24 HDMI inputs for option. Every 8 HDMI ports share one encoder module with each module supporting 1MPTS and 8 SPTS output. Its high integration and cost effective design makes the device widely used in varieties of digital distribution systems such as cable TV digital head-end, digital TV broadcasting etc.
Main Features
- 8 HDMI inputs with 8 SPTS and 1 MPTS output (each encoder module), max 24 HDMI inputs
- MPEG4 AVC/H.264 video encoding format
- MPEG1 Layer II, LC-AAC，HE-AAC audio encoding format and AC3 Pass Through, and audio gain adjustment
- IP output over UDP and RTP/RTSP protocol; 1 ASI out as mirror of MPTS (Optional)
- Support QR code, LOGO, caption insertion (Language Supported: 中文, English, ةيبرعلا, ไทย, हिन्दी, русский, ودرا for more languages please consult us…)
- Support “Null PKT Filter” function
- Control via web management, and easy updates via web
Encoder HD 8X NetUP Datasheet
Design
Rackmount 19”, 1U
Power: 220V A.C., 50/60 Hz
Dimensions: 480 х 44 х 415 mm
Performance
H.264, up to 13Mbps per channel
Up to1080х30p
MPEG Layer II for audio
Interfaces
1-3 Gigabit Ethernet
8, 16, 24 HDMI-inputs
