airMAX 5GHz 10dBi Omni
- airMAX 5 GHz, 10 dBi Omni
- AMO-5G10 support 5 GHz, 10 dBi carrier-class 2×2 dual-polarity MIMO omnidirectional antenna
- 2×2 dual-polarity MIMO
- 360° coverage
- Easy to assemble
- Compatible with RocketPrism
Zalo:
- Kinh Doanh OnlineWhatsApp:
- Tư Vấn Giải PhápFacebook:
- Hỗ Trợ Đơn HàngSales Engineer:
- 0989 544 978×
Technical Specifications airMAX 5 GHz, 10 dBi Omni
| Dimensions | 582 x 90 x 65 mm (22.9 x 3.5 x 2.6″) |
| Weight | 680 g (1.5 lb) |
| Frequency Range | 5.45 – 5.85 GHz |
| Gain | 10 dBi |
| Elevation Beamwidth | 12° |
| Max. VSWR | 1.6:1 |
| Downtilt | 4° |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 44.5 N @ 160 km/h (10 lbf @ 100 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 25 dB min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
