airMAX 2.4GHz 10dBi Omni
- airMAX 2.4 GHz, 10 dBi Omni
- AMO-2G10 support 2.4 GHz, 10 dBi carrier-class 2×2 dual-polarity MIMO omnidirectional antenna
- 2×2 dual-polarity MIMO
- 360° coverage
- Easy to assemble
- Compatible with RocketPrism
Ms Nhan:
- Kinh Doanh
Mr Minh: - Kinh Doanh
Mr Luân: - Kinh Doanh
WhatsApp: - Tư Vấn Giải Pháp
Facebook: - Hỗ Trợ Đơn Hàng
Sales Engineer: - 0989 544 978
Hotline: 0933 719 613
- Kinh Doanh
Mr Minh:
- Kinh Doanh
Mr Luân:
- Kinh DoanhWhatsApp:
- Tư Vấn Giải PhápFacebook:
- Hỗ Trợ Đơn HàngSales Engineer:
- 0989 544 978×
Technical Specifications airMAX 2.4 GHz, 10 dBi Omni
| Dimensions | 1030 x 122 x 84 mm (40.6 x 4.8 x 3.3″) |
| Weight | 2.1 kg (4.6 lb) |
| Frequency Range | 2.35 – 2.55 GHz |
| Gain | 2.35 – 2.55 GHz |
| Elevation Beamwidth | 12° |
| Max. VSWR | 1.7:1 |
| Downtilt | 4° |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 62.3 N @ 160 km/h (14 lbf @ 100 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 25 dB min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
